頂軸式收放料座
Shaft-less un/rewinding unit
Product Description
精益求精！瑋禮發展乾式及無溶劑兩用貼合機，滿足多樣化包裝需求！
一次加工可達到同時三層貼合生產！！
乾式及無溶劑兩用貼合機WDSL系列以及無溶劑貼合機WSL系列，是無溶劑首屈一指的熱門機種，能有更高的複合速度增加產能效率，無任何溶劑揮發而造成的成本浪費。黏著劑的固含量 100%，上膠量的厚度也很薄非常節省成本。廠房無需安裝防爆設備，無揮發溶劑且無任何溶劑殘留，符合食品安全規章。此外，無需乾燥烘箱所以可節省乾燥電熱或瓦斯的能源消耗成本。乾式及無溶劑兩用機型也可因應訂單，可選擇單獨使用乾式貼合或是無溶劑貼合功能，或者乾式+無溶劑貼合同時一次生產三層貼合產品(圖解)，因此可配合更多方位的應用，且機身可更短小節省占地空間以利廠房更多的利用，大幅的降低成本、提升生產效率。
五輪式上膠座
5 roll coating system
Specifications
| 機型 | WSL |
|---|---|
| 最大機械速度 | 310 m/min |
| 貼合速度 | 300 m/min |
| 貼合寬度 | 1000 mm / 1200 mm / 1300 mm |
| 材料直徑 | Ø600 mm / Ø800 mm / Ø1000 mm |
Applications
PET, CPP, PVC,OPP, PP, PE, Nylon, Aluminum Foil, Paper.
Alu alu foil
冷凍食品外包裝
沙拉油包、洗衣精
咖啡粉包類
料理包
能量飲料軟包裝類
零食袋
鋁箔紙印刷
糖果包裝
Frequently Asked Questions
Common questions about the WSL series solventless laminating machine
Q1
What is a solventless laminating machine?
+
A solventless laminating machine bonds two or more flexible films using 100% solids adhesive with no solvent and no drying oven. Because nothing evaporates, there is no solvent residue, energy use is lower, and lamination speed is higher, making solventless lamination the leading eco-friendly choice for food-safe flexible packaging.
Q2
What is the difference between solventless and dry (solvent-based) lamination?
+
Dry lamination uses solvent-diluted adhesive that must pass through a drying chamber, while solventless lamination applies 100% solid adhesive directly with no drying required. Solventless offers lower energy cost, faster speed, and zero solvent residue; dry lamination still suits certain high-performance structures like retort packaging. Worldly manufactures both machine types.
Q3
Is solventless lamination safe for food packaging?
+
Yes. Since no solvent is used, there is no risk of residual solvent migrating into food, and the process conforms to food safety regulations. This is why solventless laminating machines are widely used for snack bags, coffee pouches, frozen food packaging, and other direct food-contact flexible packaging.
Q4
What materials can the WSL solventless laminating machine handle?
+
The WSL series laminates PET, OPP, CPP, PP, PE, PVC, nylon, aluminium foil, and paper. This covers most common flexible packaging structures, from clear snack films to high-barrier foil laminates such as alu-alu cold form foil and coffee packaging.
Q5
What is the laminating speed of the WSL series?
+
The WSL series solventless laminating machine runs at laminating speeds up to 300 m/min with a maximum machine speed of 310 m/min, in web widths of 1000, 1200, or 1300 mm. The five-roll coating system maintains a uniform, ultra-thin adhesive layer even at full production speed.
Q6
How does solventless lamination reduce production cost?
+
Cost savings come from four directions: no solvent purchase, no adhesive lost to evaporation, a much thinner adhesive coating weight thanks to 100% solids, and no drying chamber, which cuts energy consumption significantly. The shorter machine footprint also frees up valuable factory floor space.
Q7
What adhesives are used on a solventless laminating machine?
+
Solventless machines typically use two-component polyurethane (PU) adhesives that are mixed and metered automatically before coating. The adhesive cures by chemical reaction rather than solvent evaporation. Worldly's five-roll coating system precisely controls coating weight for consistent bond strength across the full web width.
Q8
How long does solventless lamination take to cure?
+
Laminated rolls are typically cured at controlled room temperature for around 24 to 48 hours before slitting or pouch making, depending on the adhesive system and structure. During curing, bond strength develops fully. Your adhesive supplier's data sheet determines the exact schedule for each structure.
Q9
Can the machine laminate aluminium foil?
+
Yes. Aluminium foil is one of the standard materials for the WSL series, used in structures such as alu-alu foil for pharmaceutical packaging and foil-based coffee and food pouches. The machine's precise tension control protects the fragile foil web throughout unwinding, laminating, and rewinding.
Q10
What is the difference between the WSL and the WDSL Combi type?
+
The WSL is a dedicated solventless laminating machine, while the WDSL Combi type combines solventless and solvent-based lamination in one machine and can complete a three-layer lamination in a single pass. Choose the WSL for pure solventless production, or the WDSL Combi for maximum structural flexibility.
